Product information
What to know about this model
Applications
- Applicable Industries: Garment shops, building material shops, manufacturing.
- Application: Food, beverage, commodity, medical products, chemical products, etc.
- Packaging material: Kraft paper with reinforced.
What are the advantages that FPXW-6050 could bring to the users?
- Water-activated tape carton sealer seals cartons using kraft paper tape, which is more environmentally friendly. Compared to a manual or small water-activated kraft paper dispenser, the FPXW-6050 can be adopted in a packing line with higher production.
- Sealing cartons with reinforced water-activated kraft paper gives a more solid seal than BOPP tape.
- The FPXW-6050 keeps a speed of 20 m/min, which is two times faster than other water-activated tape carton sealers in the market.
- The FPXW-6050 adopts a PLC from Omron and a touch-screen from WEINVIEW, well-known international brands, while the machine keeps a competitive price in the market.
Specifications
| Model | FPXW-6050 |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 1P |
| Power (W) | 700 |
| Max. Carton Size (L×W×H) (mm) | Unlimited×500×600 |
| Min. Carton Size (L×W×H) (mm) | 170×170×130 |
| Speed (m/min) | 20 |
| Suitable Tape | Water activity kraft paper (the machine uses glue on the inside of the tape; customization is needed when glue is on the outside) |
| Tape Width (mm) | 48-75 |
| Length of the Overlap on Sides (mm) | 48-90 |
| Max. Diameter of the Tape (mm) | 420 |
| Table Height (mm) | 700-820 |
| External Dimensions (L×W×H) (mm) | 1510×1115×(1970-2090) |
| Net Weight (kg) | 230 |
