Product information
What to know about this model
Wide Range of Application Widely Used in a Variety of Industries. Household Appliances, Textiles, Foods, Medical Care, Books, etc. Corporate Cargo Packing, Warehouse Packing. Shopping Mall Packing, E-commerce Packing. Stable Operation Double Motors & Strong Force. Strong Power Double Motors, Higher Load Capacity, Stable Transportation. Simple Operation Improve Working Efficiency. As Long as the Size Is Set, the Carton Can Be Sealed by Simply Pushing the Carton into the Device.
Specifications
| MODEL | FPCS-2550X |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Power (W) | 200 |
| Sealing Speed | 25-45 Cartons for Reference |
| Max. Carton Size (W×H) (mm) | Unlimitedx500x250 |
| Min. Carton Size (W×H) (mm) | 130\*80\*45mm |
| (When the width is more than 130mm, | the minimum height can reach at 40mm.) |
| Taping Speed (m/min) | 20 |
| Adhesive Tape Used | BOPP, Water-free Adhesive Tape, PVC Adhesive Tape |
| Height of Table (mm) | 580-780 |
| Width of Adhesive Tape (mm) | 36,48 |
| External Dimensions (L×W×H) (mm) | 1320(with Bracket2140)x930x1200-1340mm |
| Net Weight (kg) | 125 |
| Transmission Type | Side Belt Transmission |
| Conveyor Belt Speed | 20m/min |
| Max. Loading Weight | 20kg |
| Max. External Diameter of Tape | 300mm |
