Product information
What to know about this model
Description series is designed to seal the edges of top and bottom flaps by applying adhesive tape. Conveyor belt tension and tape tension are adjustable to meet the needs of soft/hard cartons. For integration into carton sealer to form unmanned production line or as stand alone machine. Easy size changeoverst is especially ideal for applications that require high degree of leak-proofness Features √Reliable performance √Simple operation √Cost effective √High speed √Easy size changeovers √Guide rail centering mechanism √Two upper and bottom belt drive √Available for production line
Specifications
| MODEL | FPCS-8070B |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Power (W) | 360 |
| Max. Carton Size (W×H)(mm) | 700×800 |
| Min. Carton Size (W×H)(mm) | 150×130×150 |
| Speed (m/min) | 20 m/min (25-45 cartons/min) |
| Adhesive Tape Materials | BOPP, PVCadhesive tape, water-free adhesive tape |
| Height of Table (mm) | 580-780 |
| Width of Adhesive Tape (mm) | 48, 60, 76 (optional) |
| External Dimensions (L×W× H)(mm) | 1230×1100×(1620-1820) |
| Net Weight (kg) | 160 |
| Max. Conveyor Load(kg) | 50 |
