Pneumatic Coding Machine
Model: HP-501
Product Description
Hot Ribbon Coding Machine (Pneumatic) for Pneumatic Pouch Machine for printing of B.No., Mfg.Dt., Exp.Dt. etc., for Online registered printing on any intermittent FFS Machine. These coders are ideal for Semi-Automatic Coding. As soon as the product is put on the platform, coding is done automatically. The 3-line message to be printed is easily composed by pushing the Brass Stereos into the grooves & tightening them. The inking is in the form of Foil ribbon, which passes below the stereos & is advanced automatically after each print. The brass stereos are heated to a temperature of around 150 deg. C & hit the film onto the substrate thus transferring the print with embossing. These are portable, compact and easy to install units.
Specifications
| MODEL | HP-501 |
|---|---|
| Voltage (V/Hz) | 220/50 110/60 |
| Power (W) | 120 |
| Max. Printing Speed (Pcs/min) | 300 |
| Max. Printing Line | 2×3：3 lines, maximum 12characters/line(Can customized to be 6lines） |
| Size of Character(height)(mm) | 3.0 |
| Size of Color Ribbon (mm) | 25、30、35（width） |
| Frame width(mm) | 400 500 600 |
| Max. film width(mm) | 350 450 550 |
| Max. Horizontal adjusting size for printer | 220 320 420 |
| Net weight（kg） | 5 5.8 6.1 |
