Product information
What to know about this model
Description Nitrogen Flushing Packaging Machine can seal any heat-sealable materials. It has two modes — exhaust gas + sealing, and gas flushing + sealing. The print wheel equipped on the machine can be used for both R arrange and T arrange of types. For types in R arrange, the machine can print two lines in font size two (18PT) or three lines in font size five (10.5PT). If necessary, a counting device can be equipped as well.
Features
- Constant temperature control, and temperature is adjustable
- Stepless speed regulation
- Solid-ink coding featured by high definition, various selectable colors, instant dry while printing, strong adhesive property
Application Applied to pack fragile or bulky objects generally.
Specifications
| MODEL | 980ZQ |
|---|---|
| Voltage (V/Hz) | AC 220/50 110/60 |
| Motor Power (W) | 50 |
| Suction Pump Power (W) | 750 |
| Sealing Power (W) | 300×2 |
| Printing Heating Power (W) | 40×2 |
| Sealing Speed (m/min) | 0-12 |
| Sealing Width (mm) | 10 |
| Temperature Range (°C) | 0-300 |
| Printing Type | Solid Ink Roller |
| Distance from Sealing Center to Conveyor Table (mm) | 10-40 |
| Distance from Base Plate to Interior Conveyor (mm) | 68-85 |
| Conveyor Table Size (L×W) (mm) | 1054×203 |
| Overall Conveyor Loading (kg) | ≤10 |
| External Dimensions (L×W×H) (mm) | 1050×550×900 |
| Net Weight (kg) | 67 |
| Diameter of nozzle for air flushing source | 8mm |
